Spaces:
Running on Zero
Running on Zero
Upload folder using huggingface_hub
Browse files- .gitattributes +5 -0
- README.md +45 -7
- app.py +205 -0
- examples/cvc_100.png +0 -0
- examples/cvc_2.png +0 -0
- examples/real_colon_004-001_frame13.jpg +3 -0
- examples/real_colon_004-001_frame25.jpg +3 -0
- examples/real_colon_004-001_frame37.jpg +3 -0
- examples/real_colon_004-001_frame49.jpg +3 -0
- examples/real_colon_004-001_frame61.jpg +3 -0
- requirements.txt +3 -0
.gitattributes
CHANGED
|
@@ -33,3 +33,8 @@ saved_model/**/* filter=lfs diff=lfs merge=lfs -text
|
|
| 33 |
*.zip filter=lfs diff=lfs merge=lfs -text
|
| 34 |
*.zst filter=lfs diff=lfs merge=lfs -text
|
| 35 |
*tfevents* filter=lfs diff=lfs merge=lfs -text
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 33 |
*.zip filter=lfs diff=lfs merge=lfs -text
|
| 34 |
*.zst filter=lfs diff=lfs merge=lfs -text
|
| 35 |
*tfevents* filter=lfs diff=lfs merge=lfs -text
|
| 36 |
+
examples/real_colon_004-001_frame13.jpg filter=lfs diff=lfs merge=lfs -text
|
| 37 |
+
examples/real_colon_004-001_frame25.jpg filter=lfs diff=lfs merge=lfs -text
|
| 38 |
+
examples/real_colon_004-001_frame37.jpg filter=lfs diff=lfs merge=lfs -text
|
| 39 |
+
examples/real_colon_004-001_frame49.jpg filter=lfs diff=lfs merge=lfs -text
|
| 40 |
+
examples/real_colon_004-001_frame61.jpg filter=lfs diff=lfs merge=lfs -text
|
README.md
CHANGED
|
@@ -1,13 +1,51 @@
|
|
| 1 |
---
|
| 2 |
-
title:
|
| 3 |
-
emoji:
|
| 4 |
-
colorFrom:
|
| 5 |
-
colorTo:
|
| 6 |
sdk: gradio
|
| 7 |
sdk_version: 6.24.0
|
| 8 |
-
python_version: '3.12'
|
| 9 |
app_file: app.py
|
| 10 |
-
|
|
|
|
|
|
|
| 11 |
---
|
| 12 |
|
| 13 |
-
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 1 |
---
|
| 2 |
+
title: TRUE-Colon Polyp Detection
|
| 3 |
+
emoji: 🩺
|
| 4 |
+
colorFrom: purple
|
| 5 |
+
colorTo: yellow
|
| 6 |
sdk: gradio
|
| 7 |
sdk_version: 6.24.0
|
|
|
|
| 8 |
app_file: app.py
|
| 9 |
+
short_description: RT-DETR polyp detector on REAL-Colon colonoscopy frames
|
| 10 |
+
python_version: "3.12"
|
| 11 |
+
startup_duration_timeout: 30m
|
| 12 |
---
|
| 13 |
|
| 14 |
+
# TRUE-Colon: Real-Time Polyp Detection
|
| 15 |
+
|
| 16 |
+
Interactive demo of the **RT-DETR** detector from the paper *TRUE-Colon: Exposing a
|
| 17 |
+
Consistent Transfer Asymmetry in Real-Time Polyp Detection* (MICCAI 2026 EndoLINA
|
| 18 |
+
Workshop). The model was trained on **REAL-Colon** — 60 complete, unedited colonoscopy
|
| 19 |
+
procedures — and detects polyps (lesions) in individual colonoscopy frames.
|
| 20 |
+
|
| 21 |
+
## Usage
|
| 22 |
+
|
| 23 |
+
Upload a colonoscopy frame, adjust the confidence and IoU thresholds, and click
|
| 24 |
+
**Detect Polyps**. The model draws green bounding boxes around detected lesions with
|
| 25 |
+
confidence scores.
|
| 26 |
+
|
| 27 |
+
> ⚠️ **Research demo only — NOT for clinical use.** The model has not been validated
|
| 28 |
+
> prospectively or cleared by any regulator.
|
| 29 |
+
|
| 30 |
+
## Model
|
| 31 |
+
|
| 32 |
+
- **Checkpoint**: [`sdoerrich97/true_colon_rtdetr_realcolon_s0`](https://huggingface.co/sdoerrich97/true_colon_rtdetr_realcolon_s0)
|
| 33 |
+
- **Architecture**: RT-DETR (via Ultralytics)
|
| 34 |
+
- **Input**: 640 × 640
|
| 35 |
+
- **Classes**: 1 (`lesion`)
|
| 36 |
+
- **License**: AGPL-3.0 (inherited from Ultralytics training)
|
| 37 |
+
|
| 38 |
+
## Example images
|
| 39 |
+
|
| 40 |
+
Examples are from the [REAL-Colon](https://doi.org/10.1038/s41597-024-03359-0) dataset
|
| 41 |
+
(Biffi et al., *Scientific Data* 2024, CC BY 4.0) and [CVC-ClinicDB](https://polyp.grand-challenge.org/CVCClinicDB/) (CC BY 4.0).
|
| 42 |
+
|
| 43 |
+
## Citation
|
| 44 |
+
|
| 45 |
+
```bibtex
|
| 46 |
+
@article{doerrich2026truecolon,
|
| 47 |
+
title={TRUE-Colon: Exposing a Consistent Transfer Asymmetry in Real-Time Polyp Detection},
|
| 48 |
+
author={Sebastian Doerrich and Andreas Franz Schwab and Francesco {Di Salvo} and Shyam Nandan Rai and Hanh Huyen My Nguyen and Christian Ledig},
|
| 49 |
+
year={2026}, eprint={2608.13711}, archivePrefix={arXiv}, primaryClass={eess.IV}
|
| 50 |
+
}
|
| 51 |
+
```
|
app.py
ADDED
|
@@ -0,0 +1,205 @@
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 1 |
+
"""TRUE-Colon: Real-Time Polyp Detection demo.
|
| 2 |
+
|
| 3 |
+
Loads the RT-DETR checkpoint from the TRUE-Colon paper (MICCAI 2026 EndoLINA Workshop)
|
| 4 |
+
and runs inference on colonoscopy frames, drawing bounding boxes around detected polyps.
|
| 5 |
+
|
| 6 |
+
Research demo only — NOT for clinical use.
|
| 7 |
+
"""
|
| 8 |
+
|
| 9 |
+
import spaces # MUST be first
|
| 10 |
+
import os
|
| 11 |
+
import cv2
|
| 12 |
+
import numpy as np
|
| 13 |
+
import torch
|
| 14 |
+
from huggingface_hub import hf_hub_download
|
| 15 |
+
from ultralytics import YOLO
|
| 16 |
+
import gradio as gr
|
| 17 |
+
|
| 18 |
+
MODEL_ID = "sdoerrich97/true_colon_rtdetr_realcolon_s0"
|
| 19 |
+
CLASS_NAME = "lesion"
|
| 20 |
+
# Green-ish box color (BGR for cv2)
|
| 21 |
+
BOX_COLOR = (0, 255, 0)
|
| 22 |
+
|
| 23 |
+
# Download and load model at module scope
|
| 24 |
+
_weights_path = hf_hub_download(MODEL_ID, "model.pt")
|
| 25 |
+
model = YOLO(_weights_path)
|
| 26 |
+
|
| 27 |
+
|
| 28 |
+
def draw_detections(image: np.ndarray, results, conf_threshold: float) -> np.ndarray:
|
| 29 |
+
"""Draw bounding boxes on the image from Ultralytics results.
|
| 30 |
+
|
| 31 |
+
Args:
|
| 32 |
+
image: Input image as numpy array (RGB).
|
| 33 |
+
results: Ultralytics prediction results.
|
| 34 |
+
conf_threshold: Confidence threshold for display.
|
| 35 |
+
|
| 36 |
+
Returns:
|
| 37 |
+
Annotated image as numpy array (RGB).
|
| 38 |
+
"""
|
| 39 |
+
annotated = image.copy()
|
| 40 |
+
h, w = annotated.shape[:2]
|
| 41 |
+
|
| 42 |
+
for result in results:
|
| 43 |
+
boxes = result.boxes
|
| 44 |
+
for box in boxes:
|
| 45 |
+
conf = float(box.conf[0])
|
| 46 |
+
if conf < conf_threshold:
|
| 47 |
+
continue
|
| 48 |
+
cls = int(box.cls[0])
|
| 49 |
+
x1, y1, x2, y2 = box.xyxy[0].cpu().numpy()
|
| 50 |
+
x1, y1, x2, y2 = int(x1), int(y1), int(x2), int(y2)
|
| 51 |
+
|
| 52 |
+
# Draw box
|
| 53 |
+
cv2.rectangle(annotated, (x1, y1), (x2, y2), BOX_COLOR, 3)
|
| 54 |
+
|
| 55 |
+
# Draw label background
|
| 56 |
+
label = f"{CLASS_NAME} {conf:.2f}"
|
| 57 |
+
(label_w, label_h), _ = cv2.getTextSize(
|
| 58 |
+
label, cv2.FONT_HERSHEY_SIMPLEX, 0.7, 2
|
| 59 |
+
)
|
| 60 |
+
cv2.rectangle(
|
| 61 |
+
annotated,
|
| 62 |
+
(x1, y1 - label_h - 10),
|
| 63 |
+
(x1 + label_w, y1),
|
| 64 |
+
BOX_COLOR,
|
| 65 |
+
-1,
|
| 66 |
+
)
|
| 67 |
+
cv2.putText(
|
| 68 |
+
annotated,
|
| 69 |
+
label,
|
| 70 |
+
(x1, y1 - 5),
|
| 71 |
+
cv2.FONT_HERSHEY_SIMPLEX,
|
| 72 |
+
0.7,
|
| 73 |
+
(0, 0, 0),
|
| 74 |
+
2,
|
| 75 |
+
cv2.LINE_AA,
|
| 76 |
+
)
|
| 77 |
+
|
| 78 |
+
return annotated
|
| 79 |
+
|
| 80 |
+
|
| 81 |
+
@spaces.GPU(duration=30)
|
| 82 |
+
def detect(
|
| 83 |
+
image: np.ndarray,
|
| 84 |
+
conf_threshold: float = 0.30,
|
| 85 |
+
iou_threshold: float = 0.50,
|
| 86 |
+
) -> np.ndarray:
|
| 87 |
+
"""Detect polyps in a colonoscopy frame.
|
| 88 |
+
|
| 89 |
+
Runs the TRUE-Colon RT-DETR detector on the input image and returns an
|
| 90 |
+
annotated copy with bounding boxes around detected lesions.
|
| 91 |
+
|
| 92 |
+
Args:
|
| 93 |
+
image: Colonoscopy frame as an image.
|
| 94 |
+
conf_threshold: Minimum detection confidence to display.
|
| 95 |
+
iou_threshold: NMS IoU threshold.
|
| 96 |
+
|
| 97 |
+
Returns:
|
| 98 |
+
Annotated image with detection boxes drawn.
|
| 99 |
+
"""
|
| 100 |
+
if image is None:
|
| 101 |
+
return None
|
| 102 |
+
|
| 103 |
+
# Ultralytics expects RGB; Gradio passes RGB
|
| 104 |
+
results = model.predict(
|
| 105 |
+
source=image,
|
| 106 |
+
conf=conf_threshold,
|
| 107 |
+
iou=iou_threshold,
|
| 108 |
+
imgsz=640,
|
| 109 |
+
verbose=False,
|
| 110 |
+
)
|
| 111 |
+
|
| 112 |
+
annotated = draw_detections(image, results, conf_threshold)
|
| 113 |
+
return annotated
|
| 114 |
+
|
| 115 |
+
|
| 116 |
+
CSS = """
|
| 117 |
+
#col-container { max-width: 1100px; margin: 0 auto; }
|
| 118 |
+
.dark .gradio-container { color: var(--body-text-color); }
|
| 119 |
+
"""
|
| 120 |
+
|
| 121 |
+
EXAMPLES = [
|
| 122 |
+
["examples/real_colon_004-001_frame13.jpg"],
|
| 123 |
+
["examples/real_colon_004-001_frame25.jpg"],
|
| 124 |
+
["examples/real_colon_004-001_frame37.jpg"],
|
| 125 |
+
["examples/real_colon_004-001_frame49.jpg"],
|
| 126 |
+
["examples/cvc_2.png"],
|
| 127 |
+
["examples/cvc_100.png"],
|
| 128 |
+
]
|
| 129 |
+
|
| 130 |
+
with gr.Blocks(theme=gr.themes.Citrus(), css=CSS) as demo:
|
| 131 |
+
with gr.Column(elem_id="col-container"):
|
| 132 |
+
gr.Markdown(
|
| 133 |
+
"""
|
| 134 |
+
# 🩺 TRUE-Colon: Real-Time Polyp Detection
|
| 135 |
+
**RT-DETR** trained on REAL-Colon (60 full colonoscopy procedures) for polyp detection.
|
| 136 |
+
From the paper *TRUE-Colon: Exposing a Consistent Transfer Asymmetry in Real-Time Polyp Detection* (MICCAI 2026 EndoLINA).
|
| 137 |
+
|
| 138 |
+
[📄 Paper](https://arxiv.org/abs/2608.13711) | [🐍 Code](https://github.com/sdoerrich97/true-colon) | [⚖️ Weights](https://huggingface.co/sdoerrich97/true_colon_rtdetr_realcolon_s0)
|
| 139 |
+
|
| 140 |
+
> ⚠️ **Research demo only — NOT for clinical use.** The model has not been validated prospectively or cleared by any regulator.
|
| 141 |
+
"""
|
| 142 |
+
)
|
| 143 |
+
|
| 144 |
+
with gr.Row():
|
| 145 |
+
with gr.Column(scale=1):
|
| 146 |
+
input_image = gr.Image(
|
| 147 |
+
label="Colonoscopy Frame",
|
| 148 |
+
type="numpy",
|
| 149 |
+
sources=["upload", "clipboard"],
|
| 150 |
+
)
|
| 151 |
+
conf_slider = gr.Slider(
|
| 152 |
+
label="Confidence Threshold",
|
| 153 |
+
minimum=0.05,
|
| 154 |
+
maximum=0.95,
|
| 155 |
+
step=0.05,
|
| 156 |
+
value=0.30,
|
| 157 |
+
)
|
| 158 |
+
iou_slider = gr.Slider(
|
| 159 |
+
label="NMS IoU Threshold",
|
| 160 |
+
minimum=0.10,
|
| 161 |
+
maximum=0.95,
|
| 162 |
+
step=0.05,
|
| 163 |
+
value=0.50,
|
| 164 |
+
)
|
| 165 |
+
run_btn = gr.Button("Detect Polyps", variant="primary")
|
| 166 |
+
|
| 167 |
+
with gr.Column(scale=1):
|
| 168 |
+
output_image = gr.Image(
|
| 169 |
+
label="Detection Result",
|
| 170 |
+
type="numpy",
|
| 171 |
+
)
|
| 172 |
+
|
| 173 |
+
run_btn.click(
|
| 174 |
+
fn=detect,
|
| 175 |
+
inputs=[input_image, conf_slider, iou_slider],
|
| 176 |
+
outputs=[output_image],
|
| 177 |
+
api_name="detect",
|
| 178 |
+
)
|
| 179 |
+
|
| 180 |
+
gr.Examples(
|
| 181 |
+
examples=EXAMPLES,
|
| 182 |
+
inputs=[input_image],
|
| 183 |
+
outputs=[output_image],
|
| 184 |
+
fn=detect,
|
| 185 |
+
cache_examples=True,
|
| 186 |
+
cache_mode="lazy",
|
| 187 |
+
)
|
| 188 |
+
|
| 189 |
+
gr.Markdown(
|
| 190 |
+
"""
|
| 191 |
+
### Example image sources
|
| 192 |
+
Examples from the [REAL-Colon](https://doi.org/10.1038/s41597-024-03359-0) dataset (Biffi et al., *Scientific Data* 2024, CC BY 4.0) and [CVC-ClinicDB](https://polyp.grand-challenge.org/CVCClinicDB/) (CC BY 4.0).
|
| 193 |
+
|
| 194 |
+
### Citation
|
| 195 |
+
```bibtex
|
| 196 |
+
@article{doerrich2026truecolon,
|
| 197 |
+
title={TRUE-Colon: Exposing a Consistent Transfer Asymmetry in Real-Time Polyp Detection},
|
| 198 |
+
author={Sebastian Doerrich and Andreas Franz Schwab and Francesco {Di Salvo} and Shyam Nandan Rai and Hanh Huyen My Nguyen and Christian Ledig},
|
| 199 |
+
year={2026}, eprint={2608.13711}, archivePrefix={arXiv}, primaryClass={eess.IV}
|
| 200 |
+
}
|
| 201 |
+
```
|
| 202 |
+
"""
|
| 203 |
+
)
|
| 204 |
+
|
| 205 |
+
demo.launch(mcp_server=True)
|
examples/cvc_100.png
ADDED
|
examples/cvc_2.png
ADDED
|
examples/real_colon_004-001_frame13.jpg
ADDED
|
Git LFS Details
|
examples/real_colon_004-001_frame25.jpg
ADDED
|
Git LFS Details
|
examples/real_colon_004-001_frame37.jpg
ADDED
|
Git LFS Details
|
examples/real_colon_004-001_frame49.jpg
ADDED
|
Git LFS Details
|
examples/real_colon_004-001_frame61.jpg
ADDED
|
Git LFS Details
|
requirements.txt
ADDED
|
@@ -0,0 +1,3 @@
|
|
|
|
|
|
|
|
|
|
|
|
|
| 1 |
+
ultralytics>=8.3.223
|
| 2 |
+
opencv-python-headless
|
| 3 |
+
numpy
|
